Answer

Brief Explanations:

The image depicts the structure of a sarcomere, the functional unit of skeletal muscle. The labels are determined based on the following anatomical features:

  1. Z disc: The boundary lines that anchor thin filaments.
  2. Thick filament: Composed of myosin, shown in orange with protruding heads.
  3. Thin filament: Composed of actin, shown as the red helical structures.
  4. Sarcomere: The entire segment from one Z disc to the next.
  5. A band: The dark region spanning the entire length of the thick filaments.
  6. I band: The light region containing only thin filaments, bisected by the Z disc.
  7. H zone: The central region of the A band containing only thick filaments.

Answer:

Top labels (from left to right):

  1. Z disc
  2. Thick filament
  3. Thin filament

Right side label: Sarcomere

Left side labels (from top to bottom):

  1. I band
  2. H zone
  3. A band
