the entire graph of the function f is shown in the figure below. write the domain and range of f as…

Explanation:

Step1: Identify domain from x - values

The left - most x - value of the graph is $x=-2$ (closed - circle, included) and the right - most x - value is $x = 4$ (closed - circle, included). So the domain is all x - values between these two points.

Step2: Identify range from y - values

The lowest y - value of the graph is $y=-5$ (open - circle, not included) and the highest y - value is $y = 3$ (closed - circle, included). So the range is all y - values between these two points.

Answer:

domain = $[-2,4]$ range = $(-5,3]$
