the entire graph of the function g is shown in the figure below. write the domain and range of g using…

Explanation:

Step1: Identify domain from x - values

The left - most x - value is a closed - circle at (x=- 5) and the right - most x - value is an open - circle at (x = 4). So the domain is all real numbers (x) such that (-5\leqslant x<4), written in interval notation as ([-5,4)).

Step2: Identify range from y - values

The lowest y - value is a closed - circle at (y=-5) and the highest y - value is an open - circle at (y = 5). So the range is all real numbers (y) such that (-5\leqslant y<5), written in interval notation as ([-5,5)).

Answer:

Domain: ([-5,4)), Range: ([-5,5))
